ShangHai SPV Special Vehicle Co., Ltd.
Corrugated cargo van (also called box vehicle, cargo truck, cargo van, box van, cube truck, cargo van) is used to transport cargo with closed box. It is very normal and important transport truck.
The material used for van truck body could be corrugated steel, color steel plate, fiberglass, aluminum…
By adding cooling system and polyurethane insulation layer, van truck could be refrigeration truck and carry cargo or food that need be in low temperature.
According to the requirements, it could be single door at rear or side, or double door.
---- ISUZU chassis ensures perfect driving performance.
---- ISUZU engine, super powerful; reliable performance.
---- Nice shape, rational structure
---- Prolonged service life
| Corrugated Box Van ISUZU (2 Tons) | ||
| General | Vehicle Brand | SPV |
| Chassis Brand | ISUZU | |
| Overall Dimension | 5995 * 2300 * 3200 mm | |
| GVW / Kerb Weight | 7,300 kg / 3,800 kg | |
| Cab | Cab Capacity | 2 persons allowed |
| Air Conditioner | Air Conditioner Equipped | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU | |
| Power | 120 Hp (88 KW) | |
| Displacement | 2999 ml | |
| Emission Standard | Euro VI | |
| Chassis | Drive Type | 4X2, left hand drive |
| Transmission | Manual, 5 forward,1 reverse | |
| Wheelbase/No. of axle | 3360 mm / 2 | |
| Tyre Specification | 7.00R16 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 98 km/h | |
| Paint | Metallic paint | |
| Superstructure | Box Capacity | 3 tons |
| Box Material | Corrugated steel | |
| Dimension of Box | 4250 x 2050 x 2100 mm | |
| All standard accessories: tool kit, English Manual…… | ||
| Optional |
** Tank material could be color steel plate, fiberglass, aluminum… ** Cooling system and polyurethane insulation layer. |
|
