ShangHai SPV Special Vehicle Co., Ltd.
Fuel hauling truck (also called fuel tansport truck, truck mounted fuel bowser, truck mounted fuel tank, fuel carrying truck, highway fuel bowser, petrol fuel tank, oil tank truck, fuel dispenser, diesel mobile tanker, petrol bowser, crude oil tanker, fuel transfer tanker, aircraft refueling truck, fuel storage truck, fuel tanker) is used to transport oil, diesel, gasoline, kerosene, etc.
It can be divided into many compartments to transport different types of fuels, lubricant, crude oil, alcohol……
Oil pump equipped, with pump in pump out function.
---- Sinotruk chassis, perfect performance.
---- WeiChai engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure.
---- Fuel pump super powerful, highly efficient, with pump in pump out function.
---- Massive, durable, long service life.
| Fuel Hauling Truck Sinotruk Howo ( 20,000 Litres ) | ||
| General | Vehicle Brand | SPV |
| Chassis Brand | Sinotruk | |
| Overall Dimension | 9900 * 2540 * 3230 mm | |
| GVW / Kerb Weight | 25,000 kg / 14,700 kg | |
| Cab | Cab Capacity | 2 persons seats with 1 sleeper |
| Air Conditioner | Equipped | |
| Engine | Fuel Type | Diesel |
| Engine Brand | Chinese top engine - WEICHAI | |
| Power | 380 Ps (294 KW) | |
| Displacement | 11600 ml | |
| Emission Standard | Euro VI | |
| Chassis | Drive Type | 6X4, left hand drive |
| Transmission | 10 - speed forward, 2 reverse | |
| No. of Axles | 3 | |
| Tyre Specification | 12.00R24 | |
| Tyre Number | 10 tyres and 1 spare tyre | |
| Max Speed | 80 km/h | |
| Paint | Metallic paint | |
| Superstructure | Tank Capacity | 20,000 Litres ( About 5,300 gallons) |
| Tank Material | Carbon steel | |
| Pump | Fuel pump equipped for overhead delivery | |
| Suction Head | 6 m | |
| Hose | High quality, wire strengthened hose, with cooper wire, anti-static | |
| All standard accessories: manhole, ladder, anti-static belt, anti-slip walkway, handrail, fire extinguisher, inlet, discharge, reflective stickers…….. | ||
| Optional |
** Tank material could be carbon steel, stainless steel, aluminum (aluminum tanker)…… ** It can be divided into many compartments. ** Imported American mechnical pump Blackmer ** Imported American electrical pump Fillrite.... ** Devices can be equipped: flow meter, fuel dispenser, hose reel & nozzle, level gauge…… ** Heat preservation & heating system could be added. ** Bottom loading system can be equipped. |
|
