Function:
Straight boom crane truck (also called truck mounted crane, unic crane, cranetruck, lorry mounted crane, truck cargo with loader crane, knuckle boom crane on truck chassis, truck with mounted back crane, crane mounted cargo truck, truck with loading crane, boom crane, boom crane truck, articulated crane truck) is used to lift the cargo, load, transport and unload heavy stuff.
There are telescopic boom cranes, straight boom cranes and knuckle boom cranes, covering a wide range of capacities as follows:
Telescopic Boom Crane: 2Ton, 3.2Ton, 4Ton, 5Ton, 6.3Ton, 8Ton, 10Ton, 12Ton, 14Ton, 16Ton, 25Ton
Knuckle Boom Crane: 1Ton, 2Ton, 3.2Ton, 4Ton, 5Ton, 6.3Ton, 8Ton, 10Ton, 12Ton, 14Ton, 16Ton, 25Ton.
The cranes can be of famous brands as Palfinger (Canada), Unic (Japan), Tadano (Japan), XCMG (China top brand), Zoomlion, etc.
Features:
---- ISUZU chassis ensures perfect driving performance.
---- ISUZU engine, super powerful; reliable performance.
---- Premium cranes Palfinger (Canada), Unic (Japan), Tadano (Japan), XCMG (China top brand), Zoomlion, etc.
---- Key hydraulic components are of top international technologies, which make the operation safe and reliable.
Specification:
Similar Key Words: ISUZU truck mounted crane, ISUZU boom truck, truck mounted boom lift, knuckle boom crane on truck chassis, truck mounted knuckle boom crane, truck mounted hydraulic crane, crane mounted cargo truck, boom crane
|
Straight Boom Truck Crane ISUZU (15 Tons Crane Truck) |
|
General |
Vehicle Brand |
SPV |
|
Chassis Brand |
ISUZU |
|
Overall Dimension |
12000 x 2550 x 3910 mm |
|
GVW / Kerb Weight |
31,000 kg / 19,200 kg |
|
Cab |
Cab Capacity |
3 persons allowed |
|
Air Conditioner |
Equipped Air conditioner |
|
Engine |
Fuel Type |
Diesel |
|
Engine Brand |
ISUZU |
|
Power |
315 Hp (232 KW) |
|
Displacement |
9460 ml |
|
Emission Standard |
Euro V |
|
Chassis |
Drive Type |
8X4, left hand drive |
|
Transmission |
ISUZU MSB 10 forward gears and 2 reverse |
|
Wheelbase/No. of axle |
4 |
|
Tyre Specification |
11.00R20 |
|
Tyre Number |
12 tyres and 1 spare tyre |
|
Max Speed |
90 km/h |
|
Paint |
Metallic paint |
|
Superstructure |
Cargo Box Dimension |
8400 X 2450 X 600 mm |
|
Crane Type |
Straight boom crane |
|
Max Lifting Capacity |
15000 kg |
|
Slewing Angle |
360°all rotation |
|
All other standard accessories: Tool kit, English manual |
|
Optional |
1. Knuckle boom crane.
2. Hydraulic tipper box.
3. Box thickness according to requirement.
4. Box height could be nominated. |
ISUZU Straight Boom Crane Truck - Front Side View
ISUZU Truck Mounted Straight Boom Crane - Left Front Side View
ISUZU Truck With Loading Crane - Left Back Side View
