Home > Tank Truck > Water Bowser
Water Bowser JAC
10,000 Litres Camión Cisterna
Water Bowser JAC
Function:

Water bowser (also called Camión cisterna, water tanker truck, water tank lorry, mobile water truck, water tank, water bowser truck, water truck sprinkler, drinkable water truck) is used to transport and supply water, whatever industrial or agriculture water, widely used in construction engineering, farm irrigation, draught relief, etc.

With non-toxic treatment inside tank or tank made of stainless steel, the water tank truck can be suitable for transporting drinking water, called as potable water tanker, drinking water tanker, stainless steel water tanker, agua potavel, safe to human body.

Water tanker can also be equipped with special sprayers to achieve front flush, rear sprinkle, side spray, to sprinkle and clean the roads, streeets for environmental sanitation and protection, called as water sprinkler, water spray truck.
With rear working platform and high cannon, the Water lorry can also be used to water the plants, even high trees in virescence, called as watering truck.

Water bowser can be also equipped with pesticide spraying machine, to be used to spray pesticide in agriculture pest control field.

Features:

---- Nice shape, rational structure
---- A separate HONDA Water gasoline pump equiped, super powerful, efficient pump in and out
---- Massive, durable, perfect performance
---- Prolonged service life



Specification:

Similar Key Words:  JAC, water camion, water bowser, water tank truck, water truck, water lorry

Water Bowser JAC with HONDA gasoline engine (10,000 litres)
General Vehicle Brand SPV
Chassis Brand JAC
Overall Dimension 8250 * 2495 * 3000 mm
GVW / Kerb Weight 15,950 kg / 7,455 kg
Cab Cab Capacity 3 persons allowed
Air Conditioner Air conditioner is optional
Engine Fuel Type Diesel
Engine Brand FAW engine
Power 180 Hp (143 KW)
Displacement 6740 ml
Emission Standard Euro II
Chassis Drive Type 4X2, left hand drive
Transmission 6-speed front, 1 reverse
Wheelbase/No. of axle 4500 mm / 2
Tyre Specification 10.00-20
Tyre Number 6 tyres and 1 spare tyre
Max Speed 90 km/h
Paint Metallic paint
Superstructure Tank Capacity 10,000 Litres ( About 2,600 gallons)
Tank Material Carbon steel
Pump HONDA separate gasoline pump
Delivery Head 90 m
Suction Head 6 m
Hose High quality PVC hose, anti-aging
All other standard accessories: manhole, ladder, inlet, discharge…….
Optional ** Tank material could be stainless steel or carbon steel with non-toxic treatment for potable water, safe for human body.

These water bowsers are manufactured by following advanced techniques and standards as belows:

1. Use standard steel material with enough thickness (no minus tolerance) from China famous steel plant, Special thicker material for bulkhead, ensuring long service life.
2. Global famous HONDA gasoline engine, super powerful, suction capacity 6M, delivery head 21M (it can pump water to 21M height, about 7-stories high), quick speed as 35 cubic meters per hour, (around 10 liters per second) ,convenient operation, fuel efficient, superb reliable.


Details of water tanker JAC equipped with gasoline engine pump HONDA
Water Bowser Photo 1 - Details of water tanker JAC equipped with gasoline engine pump HONDA

3. All valves are of Aluminum material, nice appearance and easy being operated.
4. The hoses are of wire braided and fiber reinforced to resist both tension and suction strength. For long sunshine time in Venezuela, the hoses are made specially uvioresistant.


Details of Water tanker equipped with gasoline engine pump HONDA 02 - hose
Water Bowser Photo 2 - Details of water tanker JAC equipped with gasoline engine pump HONDA

5. The U-shape bolts are all galvanized.
6. The hose tray locks are all stainless steel.
7. The side bumpers are of special strong material.
8. Aluminum curtain doors are used for pump box, easy operation and luxurious looking.


 Details of water tanker JAC equipped with gasoline engine pump HONDA 03
Water Bowser Photo 3 - Details of water tanker JAC equipped with gasoline engine pump HONDA

9. Tank sand blasting.
10. Two layers of prime and paint.
…………………..

These water tankers (water bowsers) stand for very high quality standard in China and same as international trend. We believe end users will be very satisfied with these tankers. And these tankers will relieve the water shortage and draught situation in Venezuela a lot.


Details of water tanker JAC equipped with gasoline engine pump HONDA - Spanish markings
Water Bowser Photo 4 - Details of water tanker JAC equipped with gasoline engine pump HONDA - Spanish markings

For the user’s convenience, we specially made user’s manual in Spanish language and operation instructions in Spanish for these water tankers. We will go for on-site training in Venezuela if end users demand.


Water tanker with gasoline engine pump HONDA on manufacturing 01
Water Bowser Photo 5 - Water tank truck JAC equipped with gasoline engine pump HONDA on manufactuing

Water tanker JAC equipped with gasoline engine pump HONDA on manufacturing 02
Water Bowser Photo 6 - Truck tanker JAC equipped with gasoline engine pump HONDA on manufacturing

water bowser JAC equipped with gasoline engine pump HONDA on manufacturing
Water Bowser Photo 7 - Water truck JAC equipped with gasoline engine pump HONDA on manufacturing


Water Bowser Photo 8 - Water lorry JAC equipped with gasoline engine pump HONDA on manufacturing

Water lorry JAC equipped with gasoline engine pump HONDA on manufaturing
Water Bowser Photo 9 - Water lorry JAC equipped with gasoline engine pump HONDA on manufacturing

Water transfer truck JAC equipped with gasoline engine pump HONDA on manufacturing
Water Bowser Photo 10 - Truck transfer tanker JAC equipped with gasoline engine pump HONDA on manufacturing


Here below are the scenes of water tankers of 2nd lot of 50 units are inspected, then parked on our factory yard ready for shipment.


Water Bowser Photo 11 - Hoses for 50 units of water tankers are on final inspection


Water Bowser Photo 12 - 50 units of water tankers are parked in the factory tidely, ready for shipment
