4 m³ Sinotruk Tipper Truck, Dump Truck, Tipper Lorry from China | SPV
Home > Construction Truck > Dump Truck
Tipper Truck Sinotruk
Dump Truck(Volume: 4 m³)
Tipper Truck Sinotruk
Function:

Tipper truck (also called dump truck, tipping truck, side-turn tipper, dump truck tipping, tipper and lorry, dumper, dump tipper, tip truck, side-turn tipper, dump truck tipping, dumper, tipper lorry) is a truck used for transporting loose material, such as sand, gravel, coal, dirt, etc.

A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front. Or hinged at side with hydraulic pistons to lift the side.



Features:

---- Sinotruk China chassis ensures perfect driving performance.
---- Chaoyang engine,  super powerful; reliable performance.
---- Nice shape, rational structure
---- High strength box body
---- Excellent Chinese brand hydraulic piston
---- Strong, durable, perfect performance
---- Prolonged service life



Specification:

Tipper Truck Sinotruk (Volume: 4 m³)
General Vehicle Brand SPV
Chassis Brand Sinotruk
Overall Dimension 5700 * 2100 * 2300 mm
GVW / Kerb Weight 5,500 kg / 3,200 kg
Cab Cab Capacity 3 person's seat
Air Conditioner With air conditioner
Engine Fuel Type Diesel
Engine Brand Chaoyang engine
Power 120 Hp (88 KW)
Displacement 3856 ml
Emission Standard Euro II
Chassis Drive Type 4X2, left hand or right hand drive
Transmission 5-speed forward, 1 reverse
Wheelbase/No. of axle 3360 mm / 2
Front Axle 2 Tons
Rear Axle 3.5 Tons
Tyre Specification 7.00R16, radial tyre, super wearable
Tyre Number 6 tyres and 1 spare tyre
Max Speed 95 km/h
Paint Metallic paint
Superstructure Box Volume 5 m³
Box Dimension 3800 * 1900 * 500 mm
Box Thickness Side board: 3 mm
Floor board: 4 mm
Hydraulic System Famous Chinese brand, middle lift
All other standard accessories: Tool kit, English manual
Optional ** Box thickness could be nominated.
** Box height could be nominated.
** Tip way: back or side.

4 CBM Tipper Truck SINOTRUK - LF
Left front view of 4 CBM Tipper Truck Sinotruk

4 CBM Tipper Truck SINOTRUK - B
Left back view of 4 CBM Tipper Truck Sinotruk

4 CBM Tipper Truck SINOTRUK - RB
Right front view of 4 CBM Tipper Truck Sinotruk
